Duct Fan 100 mm, 156 Pa, 26 W, 230 V, IP44, Inline Fan, Ferono

Quick Facts — FKP100 Duct fan

• Model: FKP100
• Type: Duct fan (inline fan)
• Diameter Ø: 100 mm
• Voltage: 230 V
• Power: 26 - 23 W
• Air pressure: 156 - 131 Pa
• Protection class: IP44

Duct fan FKP100 from Ferono is a plastic inline fan for round ventilation ducts of Ø 100 mm, built for 230 V and IP44. It delivers 156 - 131 Pa of air pressure at 26 - 23 W and is connected through a connection box.

Two speeds, high and low, give 2200 - 1850 RPM and a noise level of 31 - 26 dB. The motor is brushless, supports voltage regulation and has built-in thermal motor protection via a temperature sensor. The insulation class is F.

What makes duct fan FKP100 a strong choice for ventilating offices, shops and restrooms?

The answer lies in the combination of two speeds, a brushless motor and a Ø 100 mm connection to round ventilation ducts. High and low speed adapt the fan to the need, with 156 - 131 Pa of air pressure and a noise level of 31 - 26 dB. Casing and blades are made of plastic, and the oval shape prevents dirt and dust from collecting, which maintains efficiency over time.

Is duct fan FKP100 suited to restrooms and production facilities?

Yes, within the operating temperature of –10°C to 60°C. IP44 withstands splashes but not hosing down.

The fan is used for ventilation in the following settings:

• Homes
• Offices
• Laboratories
• Restrooms
• Shops
• Production facilities

Technical Specifications

Used by: Ventilation fitters, electricians, facility caretakers, service technicians and laboratory technicians.

Common in: Ventilation trade, property management, retail, laboratories and light production.

Frequently Asked Questions (FAQ)

Does duct fan FKP100 work with ventilation systems that have two-speed motors?

Yes. FKP100 is only compatible with ventilation systems that have two-speed motors. The fan has two speeds, high and low, at 2200 - 1850 RPM, and the brushless motor supports voltage regulation at 230 V and 50 Hz.

How is the motor in duct fan FKP100 protected against overheating?

The motor has built-in thermal motor protection that is activated via a temperature sensor. The insulation class is F, the sealing class IP44 and the operating temperature –10°C to 60°C.

What sets duct fan FKP100 apart from other duct fans?

FKP100 has a plastic casing and blades, an oval shape that prevents dirt and dust from collecting, a brushless motor with voltage regulation and two speeds. It delivers 156 - 131 Pa of air pressure, has a Ø 100 mm connection and comes with a connection box.
