Laser Distance Meter 50 m, CE, Proline

Quick Facts — 15197 Laser distance meter

• Model: 15197
• EAN: 5903755193193
• Type: Laser distance meter
• Range: 50 m
• Laser class: II, 620-690 nm, <1 mW
• Ingress protection: IP 54
• Measurement time: 0.5 sec
• Memory: 99 measurements

Laser distance meter for measuring up to 50 m with laser class II and IP 54, built for measuring on site and in installation work. The Proline instrument measures in 0.5 sec and stores 99 measurements.

Measurement can start from the front or the back of the instrument. Besides single and continuous measurement it offers direct and indirect measurement using the Pythagorean theorem and area and volume calculation. Measurements can be added and subtracted.

The instrument measures 120 mm x 50 mm x 25 mm and weighs 92 g±5 g. The batteries (AAA, 3 x 1.5 V) last up to 5000 measurements, and the LCD screen shows the result.

When does laser distance meter 15197 make the most sense?

It makes the most sense when lengths, areas and volumes need to be established quickly without a tape measure. The 50 m range covers rooms, façades and longer runs.

The functions of the instrument are used for tasks such as:

• Single and continuous measurement of distances
• Direct and indirect measurement with the Pythagorean theorem
• Area and volume calculation
• Adding and subtracting stored measurements
• Choice of front or back as the starting point

Is laser distance meter 15197 suited to indoor and outdoor work?

Yes, within the limits set by IP 54 and the temperature range. IP 54 protects against dust and splashes, but the instrument does not withstand hosing or immersion. Working temperature is 0 °C to +40 °C and storage is permitted from -20 °C to +65 °C.

Automatic switch-off occurs after 5 min, which saves battery during longer shifts.

Technical Specifications

Package Contents

• Laser distance meter
• Instruction manual
• Box

Suitable for: Site managers and foremen who take off dimensions. Estimators and inspectors who measure area and volume. Carpenters and floor layers who measure rooms. Installers who measure runs and heights.

Industries: Construction. Property management. Flooring and interior fit-out. Installation and plumbing. Roofing.

Frequently Asked Questions (FAQ)

Does laser distance meter 15197 work in rain and when hosed?

No, not when hosed. IP 54 protects against dust and splashes but not against hosing or immersion. The working temperature of laser distance meter 15197 is 0 °C to +40 °C.

How long do the batteries last in laser distance meter 15197?

Three AAA batteries of 1.5 V each last up to 5000 measurements. The instrument switches off automatically after 5 min and stores 99 measurements.

What distinguishes laser distance meter 15197 from other distance meters?

Laser distance meter 15197 measures up to 50 m in 0.5 sec, has IP 54 and calculates area, volume and distances with the Pythagorean theorem. The starting point can be set to the front or back, and measurements can be added and subtracted.
