What is the FPT350 and when should it be used?
Maximize airflow efficiency with this powerful wall-mounted exhaust fan, engineered for demanding commercial and industrial environments. With a capacity of 3500 m³/h and a durable metal construction, it is ideal for rapidly extracting moisture, odors, and heat. Its wide operating temperature range and IP44 rating make it suitable for everything from cold garages to hot production halls.
Key Features
- High Performance: Aerodynamic pressed metal blades ensure maximum airflow with minimal noise.
- Robust Build: Metal motor and blades, featuring safety guards on both sides.
- Long Lifespan: Equipped with double ball bearings for extended operational life.
- Safe Operation: Built-in thermal protection against overheating and insulation class F.
- Extreme Temp Resistance: Operates efficiently in temperatures from –20°C up to +80°C.
- Flexible Installation: Can be mounted in any position (horizontal or vertical).
Technical Specifications
| Performance & Power | |
|---|---|
| Model | FPT350 |
| Airflow | 3500 m³/h |
| Speed | 1400 RPM |
| Air Pressure | 58 Pa |
| Power | 140 W |
| Current | 0.65 A |
| Voltage / Frequency | 230 V / 50 Hz |
| Noise Level | 64 dB |
| IP Class | IP44 |
| Capacitor | 4 μF / 450 V |
| Weight (Net/Gross) | 6.5 / 7.2 kg |
Dimensions (mm)
| Diameter (Ø) | 350 mm |
| A (External Width) | 375 mm |
| B (Hole Width) | 370 mm |
| C (External Height) | 420 mm |
| D (Depth) | 136.5 mm |
| E (Mounting Hole) | 12 mm |
Applications & Industries
This fan is designed for professionals requiring reliable ventilation. It is perfectly suited for installation in:
- Workshops and garages
- Warehouses and logistics centers
- Industrial halls and production lines
- Retail stores and commercial properties
- Machinery rooms and technical spaces
Target Audience & FAQ
Suitable for: Electricians, facility managers, HVAC installers, and warehouse supervisors.
Can the fan speed be controlled?
Yes, the brushless motor is designed for voltage regulation, allowing you to adjust the speed using an external controller (sold separately).
Can it handle hot environments?
Absolutely. The FPT350 is engineered to handle temperatures up to 80°C, which is significantly higher than many standard fans.
Is it safe to mount low on a wall?
Yes, the fan is equipped with safety guards (wire mesh) on both sides, preventing accidental contact with the blades and ensuring safety in working environments.
| Other | |
| Diameter Ø (mm) | 350 |
